Automatic ultrasonic （rotary table） plastic welder

Automatic ultrasonic (rotary table) plastic welder

Click：

Product Detail

Specifications:

Function	ZP-BZ
Machine size	11009501860mm
Working table size	700*950MM
weight	300KG
Turntable diameter	580mm(6-8Equal division)
Cylinder stroke	75MM
Power Supply	AC220V/50HZ
Frequency	15/20KHZ
power	0-3200w
welding model	time
Output time	0.001-9.999
amplitude adjustment	1%-100%

Hardware configuration table

1. Electric box: standard intelligent electric box

2. Touch screen: display and control 7 inches

3. PLC: Delta

4. Nose pneumatic parts: Yadeke / others

5. Splitter: df70

6. Pneumatic parts of main engine: domestic brand

7. Automatic blanking mechanism: Yes

Software Automatic integrated control system

Function

1. Automatic frequency tracing

2. Automatic welding and automatic blanking

3. Capacity counting, defective product shutdown

4. Whole machine centralized control operating system

5. Time, energy and other multi-mode welding

6. The whole machine's motion sensor is monitored and interlocked for protection, imitation and anti misoperation

Advantage:

Low cost , quick welding horn changing , minimum the operating cost , good matching between welding horn and transducer , high precision , which ensure the good sealing of plastic and fabric .

Packing&Shipping:

Shipping Port:Shanghai

Shipping Term:by air,by ocean .

Leading Time:Quick production leading time and fast delivery.Usually 7-20-days

When you decide to buy Ultrasonic accessories and welding machine, we support four different payment methods for you to choose

More ultrasonic welding Plastic machine technical questions ,kindly email us

Welding Machine Operation video

FAQ

1. What's the warranty of your ultrasonic spin welding machines?
One year Warranty with none human damage.
In this period factory, will responsible for repair fix it for free or the factory will send the new parts to the customer instead of the broken parts for free. After warranty time, the factory will repair fix it or send the new parts on the cost price.
2. How can I get your price and catalog?
Please E-mail us or call us to give your contact information(your name, email address, company name, and website)
3. Can we agent your spin welding machines in our country or city?
Of course. We are looking for a sole agent in the country who has the willingness to cooperate with us for a long business term.
4. How about payment?
100%T/T in advance for small orders;50%T/T in advance as a deposit;50%T/T paid before shipment.
5. Do you provide samples? is it free or extra?
Yes, we could offer the sample and it's not free.
6. could you make it according to our special requirements?

Of course, we can do that. Please tell us your idea or your application.
